Holosun Red Dot Sight HS507C 2 MOA Dot, 32 MOA Circle

HOLOSUN HS507C

The product HS507C is a open reflex red-dot-sight with
switchable reticle and solar cell. The Red Dot Sight requires only a few
microamperes as operating current. This allows an operating time up to 50,000
hours with only one battery (depending on brightness of red dot). Always on, it
is powered by solar cell under normal usage, and a back-up battery to
supplement power requirements in low light conditions.



Holosun Red Dot Sight HS507C

Reticle: 2MOA Dot, 32 MOA Circle, Switchable between Circle
Dot and Single Dot

Brightness adjustment, 12 settings for the intensity of the
red dot in order to match the ambient light conditions

Base: Picatinny/Weaver, compatible with different mounts on
request

Mount: incl. quick release mount and AR riser

Battery Lifetime LED Technology – 50.000h dot / 20.000h
circle dot

Nitrogen filling

Warranty: 3 years

With this red-dot-sight you acquired a high quality and
innovative product. Sights from Holosun are handy and robust Red Dot Sights.
They are used for hunting and shooting as well as for military and police
applications. In addition to the efficient LED-Technology, our Holosun products
feature, depending on the product type, a switchable Circle Dot, electronic
motion sensors and solar cells. The cells provide energy for autonomous power
supply. Our products can be used in combination with night vision devices.
Holosun sights are designed for open target acquisition. They allow to focus on
the target with both eyes open. Likewise the viewing distance is irrelevant.
Hereby the target acquisition accelerates significantly. Because of the
parallax free construction, the reticle always remains at the same position.

FEATURES

Battery CR2032

Protection class IP08

Housing Color black

Material 7075 Aluminium

TECHNICAL DATA

Reticle: 2MOA Red dot/32 MOA Ring

Reticle color: rot

Reticle adjustment: Eingebettete X/Y Absehenverstellung

W&E Range: ±40MOA

Size: 30.5x46x40.6mm

Weight: 75g

Lens size: 16x23mm

Surface finish: Hard anodized

Material: 7075 Aluminium

Protection Class: IP08

Housing Color: black

Battery: CR2032

MAINTENANCE AND CARE

This device is a precision optical instrument that deserves
reasonably cautious care. The following tips are provided to ensure long
lasting use of the sight.

When cleaning the lenses with a microfibre cloth or soft,
wet cloth, blow away the dust on surface first. Remove finger prints or other
oil with lens cleaner, a soft cloth or microfibre cloth. No special maintenance
is needed for the housing surface.

Avoid touching the glass surface with dry cloth or tissue
paper. Do not use organic solvents such as alcohol or acetone. Do not try to
dismantle the device as the internal parts are specially cleaned and sealed
with an anti-fog treatment. Therefore the red dot sight has a nitrogen filling
you would inevitably destroy by dismantling it. Any such attempt will avoid the
warranty. If repair is needed, you can call our customer service centre or send
us an email.

DECLARATION OF CONFORMITY

Laserluchs® GmbH

Rudolf-Diesel-Str. 2a

56070 Koblenz

Germany

takes sole responsibility in declaring that this product is in
conformity with the following standards or standardized documents:

EN 61547:2009 |EN 61000-6-1:2007-10

EN 60825-1:2015-07

in accordance with the provisions of Guidelines

2001/95/EG, 2012/19/EU, 2014/30/EU, 2011/65/EU

We constantly endeavour to optimize our products, and so we
reserve the right to modify the product specifications without prior
notification.
